Prevent Corrosion and Rust
While aluminum naturally resists corrosion better than steel, it is not immune to rust and corrosion under certain conditions. Understanding corrosion causes and implementing proper protection strategies ensures your aluminum flanges maintain optimal performance and longevity.
| Cause | Description | Risk Level |
|---|---|---|
| Moisture | Water and humidity accelerate corrosion, especially in saltwater environments | High |
| Chemicals | Acidic, alkaline, or chloride-containing fluids can attack aluminum oxide layer | High |
| Dissimilar Metals | Direct contact with steel or copper causes galvanic corrosion | Very High |
| Temperature | Elevated temperatures accelerate corrosion reactions | Moderate |
| Type | Appearance | Cause |
|---|---|---|
| Pitting | Small, deep localized holes in surface | Chlorides, moisture, incomplete oxide layer |
| Crevice | Corrosion concentrated in crevices or under gaskets | Stagnant fluid trapped in spaces |
| Galvanic | Corrosion at contact point with dissimilar metal | Two different metals in electrical contact |
Excellent barrier protection against moisture and chemicals. Provides 10+ years of protection in moderate environments. Requires proper surface preparation for adhesion.
Electrochemical process that thickens the natural oxide layer. Type II anodizing is common for flanges; Type III (hard anodizing) provides maximum durability for harsh environments.
Plasma Electrolytic Oxidation (PEO) and chromate conversion create additional protective layers. PEO is becoming the industry standard due to environmental concerns with chromate.
STEEL-IT and similar polyurethane paints provide excellent corrosion protection with quick-dry properties. Ideal for field application on existing flanges.
| Dype | Protection Level | Application |
|---|---|---|
| EPDM Rubber | Good | Low-pressure, moderate moisture |
| PTFE (Teflon) | Excellent | Chemical environments |
| Silicone Sealant | Moderate | Temporary moisture barrier |
Use plastic or fabric covers for outdoor storage. Breathable wraps prevent condensation while protecting from rain and saltwater spray.
Seal bolt holes and crevices with waterproof tape or plugs to prevent moisture from entering confined spaces where crevice corrosion can initiate.
Never bolt steel directly to aluminum. Use stainless steel bolts and washers, or isolate with non-conductive materials.
Insert plastic or rubber washers between aluminum and other metals. Use plastic bolt covers to prevent direct contact.
| Anode Material | Protection Duration | Common Use |
|---|---|---|
| Zinc | 3-5 years | General purpose |
| Magnesium | 2-4 years | Freshwater systems |
| Aluminum (special) | 5+ years | Seawater applications |
Clean flanges regularly to remove salt deposits and corrosive deposits. In marine environments, monthly cleaning is recommended. For industrial applications, quarterly inspection is typical.
Store aluminum flanges in dry, covered areas. Avoid direct contact with concrete or contaminated surfaces. Maintain proper ventilation to prevent moisture accumulation.
| Product Type | Duration | Application |
|---|---|---|
| VCI Films | 12-24 months | Storage protection |
| Desiccant Packs | Ongoing | Storage humidity control |
| Oil-based Inhibitors | 3-6 months | Surface protection |
Remove all corrosion products using wire brush, grinding, or chemical cleaning. Ensure clean, bare aluminum surface for proper coating adhesion.
For minor pitting, epoxy-based repair compounds can restore surface. For structural damage, professional welding or replacement is required.
Aluminum can be welded by qualified professionals. After welding, the oxide layer must be restored through anodizing or other protective coating.
While aluminum's natural corrosion resistance is excellent, proper protection and maintenance ensure maximum flange lifespan and reliability. By understanding corrosion causes and implementing appropriate protective strategies, you can ensure your aluminum flanges perform reliably in any environment.
